Ceiling Microphone Array Analog- X

Ceiling Microphone Array Analog- X

An advanced tri-element analog ceiling microphone array for conferencing and sound reinforcement applications with superior sound quality and adjustability for desired height.

Description
  • Most competitively-priced, “steerable” tri-element hanging mic arrays with analog interface.
  • New Significantly wider coverage area than original ClearOne CMA for larger spaces, coveringsystem covering up to 4 rooms with a single CMA system.
  • Arrays offer superior audio quality with wide bandwidth & low noise, optimized for speech-intelligibility.
  • Gets microphones “off the table” area while maintaining speech quality and intelligibility required for successful conferences.
  • At just 1.5” x 3”, it is the smallest & most unobtrusive multi-element microphone array
  • “Pre-integrated” to work seamlessly with ClearOne Audio & Video products; while also compatible with other professional systems
  • Plenum-rated for flexible placement options.
  • Multicolor LED indicators on every mic element for system status.
  • Numbered Mic elements for ease of set-up, management & troubleshooting.
  • Completely adjustable drop-down cable- between 0 and 7 feet to match most room environments.
  • Robustly Shielded against RF & Electrical interferences.
  • Attractive Capsules offered in Black or White to compliment most room environments .
Specification
ACOUSTIC CHARACTERISTICS

Element: Condenser (Electret)
Polar Pattern: 3 X 120° Cardioid Patterns, covering 360°
Signal/Noise Ratio: 74 dBA @ 1 kHz
Frequency Response: 70 Hz – 20 kHz
Sensitivity: -37dB @ 1 kHz (0 dB = 1V / Pa)
Max Sound Pressure Level: 120 dB SPL
RF Immunity: 100% immunity, fully balanced twisted pair throughout
POWER & THERMAL

DC Power: 9Vdc @ 0.5A
Impedance: 200 Ω
Operating Temperature: 41º to 104º F (5º to 40º C)
CABLES

Junction Box to Interface Box: RJ45 CAT5e/CAT6 24AWG (max 200 ft)
Junction Box to Mic Capsule: Proprietary Mic Array cable (max 7 ft)
MECHANICAL

DIMENSIONS (W x D x H):
– Mic Capsule: 1.7" x 1.7" x 86.6" (42 mm x 42 mm x 2200 mm)
– Analog-X Interface: 6.8" x 4.1" x 1.7" (172 mm x 103 mm x 43 mm)
– Analog-X Junction: 4" x 3.7" x 1.4" (102 mm x 93 mm x 35 mm)
WEIGHT:
– Mic Capsule: 6 oz (170 g)
– Analog-X Interface: 13 oz (370 g)
– Analog-X Junction: 6.5 oz (185 g)
MIC ARRAY COLOR FINISH

White or Black
COMPLIANCE

FCC, IC, CE, RoHs, WEEE, UL2043 (plenum rated)
