COLLABORATE® Live 300

COLLABORATE® Live 300

COLLABORATE® Live solutions are the most versatile video collaboration room systems of their kind in the market. COLLABORATE Live 300 is a complete video collaboration system ideal for small meeting rooms, with everything needed in a single solution for professional audio and video collaboration.

Description
  • One CHAT 150 speakerphone provides crystal-clear audio.
  • One UNITE® 160 4K Ultra HD camera with 12x optical zoom and AI-controlled Autoframing and Smart Face Tracking.
  • User interface as intuitive and simple as familiar mobile or tablet devices.
  • Monitor, control, and audit Versa Pro CT with CONVERGENCETM unified AV network management software
  • Easy to Use: User interface is as intuitive and simple as that of familiar tablets and mobile devices.
Specification
PART NUMBER

930-3001-302
COLLABORATE LIVE 300

COLLABORATE Live 300 codec appliance
UNITE 160 4K Camera
CHAT 150 speakerphone
Power supplies, cables and accessories
COLLABORATE LIVE 300 CODEC APPLIANCE

Video input: 1 x USB 3.0
Video output: 1 x HDMI, 1x Display port
Audio input: USB (Digital audio)
Audio output: USB, S/PDIF
USB: 4 x USB 3.0
UNITE 160 4K CAMERA

AI-controlled Autoframing and Smart Face Tracking
4K UHD
12x Optical Zoom
Horizontal Angle of View: 71 ° – 8.2 °
Vertical Angle of View: 42.7 ° – 4.5 °
Vertical Rotation Range: -30 ° – +90 °
Pan Speed Range: 2.7 ° – 35.7 °/s
Tilt Speed Range: 2.7 ° – 31.5 °/s
Control: IR Remote, RS-232, or UVC protocol
CHAT 150 SPEAKERPHONE

ClearOne HDConference™ audio processing
Three built-in microphone array with 360° pickup
Large loudspeaker with Max Output Level: 85 dB SPL @ 1 meter
Wideband audio frequency response (20 Hz-20 kHz)
VIDEO CHARACTERISTICS

Resolution up to 1080p @ 30 fps (Rx)
H.261, H.263, H.263+/++
H.264/AVC High Profile – up to 6 Mbps
AUDIO STANDARDS

20 KHz: AAC-LD
14 KHz: G.722.1 Annex C
7 KHz: G.722, G.722.1
3.4 KHz: G.711, G.723.1, G.728. G.729. AMR (3G)
DATA CHARACTERISTICS

H.239 support for data sharing
Resolution up to 1080p
Data inputs via wireless, datapoint (HDMI-to-USB adapter)
CONTROL

Web-based management and control
Telnet API for 3rd party control
AMX and Crestron modules
