FR1500S
Features
• Sensor: Z-ID Fingerprint Sensor
• Single gang Standard junction box installation.
• RS485 Communication Interface.
• Stainless Steel Front casing.
• Protection level of IP65; fully dust tight and resistant to water splashes from any direction.
• Flush-Mounted Design for neat installation.
Features
• Sensor: Z-ID Fingerprint Sensor
• Single gang Standard junction box installation.
• RS485 Communication Interface.
• Stainless Steel Front casing.
• Protection level of IP65; fully dust tight and resistant to water splashes from any direction.
• Flush-Mounted Design for neat installation.
| Operating Temperature | -10°C to 45°C |
|---|---|
| Operating Humidity | 20% to 95% |
| Dimension | 121.3 × 77.3 × 38 (mm) (L*W*H) |
| Algorithm Version | ZKFinger V10.0 |
| Net Weight | 14.2g |
| Gross Weight | 24.4g |
| Power Supply | DC 12V |
| Power Consumption Under Stand-by Mode | 12V * 60mA = 0.72W |
| Peak Current of Fingerprint Scanning | 140mA |
| Hardware | CPU of 1.0GHz, Z-ID Sensor, Buzzer Prompt, Three-color Indicator |
| Compatibility | inBio / inBioPro Controllers, Standalone Fingerprint Devices |
| Standard Functions | 125KHz RFID Card |
| Optional Functions | 125KHz HID Prox Card, 13.56MHz IC Card(S50 / S70), 13.56MHz HID Iclass Card |
| Communication | RS485 |
