QR10M
QR10M is a high-performance QR code reader module developed independently by ZKTeco.
QR10M is a high-performance QR code reader module developed independently by ZKTeco.The QR code module is small in size and can easily read code information from mobiles and printed materials. It can read all available codes with a built-in LED for auxiliary lighting, which has an automatic induction function to read during the day or night without significant impact. The product adopts the international leading intelligent graphic recognition system with strong recognition ability and fast recognition speed. As long as the QR code is presented at the acceptable reading angle and identification distance, the module could respond very quickly. QR10M not only has all the functions of the reader, it can also flexibly integrate applications with various products without any accessories.
| Scanner Type | QR10M |
|---|---|
| Material | Optical |
| Operating System | Windows, Linux, and Android |
| Scanning Angle | Roll: 360°, Pitch: ±40°, Yaw: ±60° |
| FOV | Horizontal: 66°, Vertical: 50° |
| Reading Distance | 5 to 25 cm |
| Image Size | 648 * 488 pixels |
| Illumination Intensity | 0 to 10000 Lux |
| One-dimensional Code Types | UPC-A, UPC-E, UPC-E1, EAN-8, EAN-13, EAN-14, EAN-128, UCC128, ISBN/ISSN, CODE11, CODE32, CODE39, CODE39 Full ASCII, CODE93, CODE128, interleaved 2 of 5, |
| Types of QR Code | QR code, PDF417, Data Matrix, MicroPDF417, and Aztec |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -40°C to 80°C |
| Operating Humidity | 5% to 93% RH (Non-condensing) |
| Operating Voltage | USB 5.0V |
| Operating Current (Working Mode) | 240mA |
| Communication Interface | USB keyboard |
| Operating Current (Idle Mode) | 50mA |
| Dimensions (L*W*H) | QR10M: 44.4 * 36.3 * 21.9 mm |
