COLLABORATE® Live 600

COLLABORATE® Live 600

COLLABORATE® Live solutions are the most versatile video collaboration room systems of their kind in the market. COLLABORATE Live 600 is a complete video collaboration system that delivers crystal-clear full duplex audio and high-quality video, perfect for mid-sized meeting rooms.

Description
  • Two CHAT 150 speakerphones that daisy-chain to provide crystal-clear audio clarity.
  • One UNITE® 260 Pro 4K Ultra HD Camera with 20X optical zoom to capture all participants in the room.
  • User interface as intuitive and simple as familiar mobile or tablet devices.
  • Monitor, control, and audit Versa Pro CT with CONVERGENCETM unified AV network management software
  • Easy to Use: User interface is as intuitive and simple as that of familiar tablets and mobile devices.
Specification
PART NUMBER

930-3001-602
COLLABORATE LIVE 600 CODEC APPLIANCE

Video inputs: 2 x HDMI (SIP/H.323), 2x USB
Video outputs: 1 x HDMI, 1x Display port
Audio inputs: Balanced audio, USB, Line in
Audio outputs: Balanced audio, Line out, HDMI
Dimensions: 17 x 8 x 2 ½ “(L x W x H)
UNITE 260 PRO CAMERA

20X Optical zoom
Horizontal Angle of View: 60.7 ° – 3.36 °
Vertical Angle of View: 34.1 ° – 1.89 °
Ultra HD 4K Camera
Pan Speed Range: 1.7 ° – 100 °/S
Tilt Speed Range: 1.7 ° – 69.9 °/S
CHAT ATTACH 150 SPEAKERPHONE

Group USB speakerphone powered by ClearOne HDConference™ audio processing
Daisy-chainable design can expand up to two complete speakerphones to cover medium-sized rooms
Three built-in microphone array with 360° pickup
Large loudspeaker with Max Output Level: 85 dB SPL @ 1 meter
Wideband audio frequency response (20 Hz-20 kHz)
VIDEO CHARACTERISTICS

Resolution up to 2160P @ 30 fps
H.261, H.263, H.263+/++
H.264/AVC High Profile – up to 6 Mbps
AUDIO STANDARDS

20 KHz: AAC-LD
14 KHz: G.722.1 Annex C
7 KHz: G.722, G.722.1
3.4 KHz: G.711, G.723.1, G.728. G.729. AMR (3G)
DATA CHARACTERISTICS

H.239 support for data sharing
Resolution up to 1080p
Data inputs via HDMI, Wireless, USB
RECORDING

Formats: MP4, WMV
Storage options: Local, external, network (NAS)
STREAMING

Format: RTSP – Unicast and multicast streaming
Max number of viewers (unicast): 20
Max number of viewers (multicast): Depends on network
CONTROL

Remote control
Web-based management and control
Telnet API for 3rd-party control
AMX and Crestron modules
