QR10L
QR10L is a high-performance QR code reader developed independently by ZKTeco.
QR10L is a high-performance QR code reader developed independently by ZKTeco. The reader is compact and could easily read code data from mobiles and printed materials. It could read all available codes with a built-in LED for auxiliary lighting, which has an automatic induction function to read during the day or night without significant impact. The product adopts an international leading intelligent graphic recognition system with strong recognition ability and fast recognition speed.
| Scanner Type | QR10L |
|---|---|
| Material | Optical |
| Dimensions (L*W*H) | QR10L: 75.5 * 53.2 * 20.1 mm |
| Operating System | Windows, Linux, and Android |
| Scanning Angle | Roll: 360°, Pitch: ±40°, Yaw: ±60° |
| FOV | Horizontal: 66°, Vertical: 50° |
| Reading Distance | 5 to 25 cm |
| Image Size | 648 * 488 pixels |
| Illumination Intensity | 0 to 10000 Lux |
| One-dimensional Code Types | UPC-A, UPC-E, UPC-E1, EAN-8, EAN-13, EAN-14, EAN-128, UCC128, ISBN/ISSN, CODE11, CODE32, CODE39, CODE39 Full ASCII, CODE93, CODE128, interleaved 2 of 5, |
| Types of QR Code | QR code, PDF417, Data Matrix, MicroPDF417, and Aztec |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -40°C to 80°C |
| Operating Humidity | 5% to 93% RH (Non-condensing) |
| Operating Voltage | USB 5.0V |
| Operating Current (Working Mode) | 240mA |
| Operating Current (Idle Mode) | 50mA |
| Communication Interface | USB keyboard |
