ZK-178S
ZK-178S is an infrared thermal imager equipped with an audio alarm. It combines surface temperature measurement and real-time thermal image detection. The traditional infrared thermometers can only measure the temperature of each accessory one by one. When compared with the conventional infrared thermometers, ZK-178S can measure the temperature of multiple accessories at once, and the potential threats will be clearly displayed on the screen.
ZK-178S is an infrared thermal imager equipped with an audio alarm. It combines surface temperature measurement and real-time thermal image detection. The traditional infrared thermometers can only measure the temperature of each accessory one by one. When compared with the conventional infrared thermometers, ZK-178S can measure the temperature of multiple accessories at once, and the potential threats will be clearly displayed on the screen. It also has a wide range of measurement and photography features that can be adapted in a variety of environments. For example, the built-in high brightness lamp can easily find a suspicious object in the dark environment. This product also adopts a new generation of the sensor module and multiple color plate mode to ensure an excellent infrared resolution and improved performance.
| Sensor | Uncooled Focal Plane |
|---|---|
| Temperature Range | 30°C ~ 45°C |
| Resolution | 0.1°C |
| Accuracy | ±0.5°C @1m |
| Optimal Measuring Distance | 1m |
| Temperature Measurement Response Time | ≤ 500ms (95% of reading) |
| Thermal Resolution | 80 * 60 |
| Pixel Dimensions | 17μm |
| Palettes | Black White, Red White, Blue White, Iron Red, Rainbow |
| Bandwidth of Infrared Spectroscopy | 8 ~ 14μm |
| Field of View (FOV) | 51° (H) * 38° (V) |
| Instantaneous Field of View (IFOV) | 11mrad |
| Thermal Imaging Sensitivity | < 150mk |
| Frame Rate | < 9Hz |
| Temperature Display | Center temperature measurement and high temperature tracking (default) |
| Image Format | BMP |
| Image Modes | Therma |
| Temperature Measuring Point | Central Point |
| Display Resolution | 320 * 240 |
| PC Analysis Software (PC) | Support |
| Data Communication | Type-C USB |
| Auto Power Off | Selectable (5min, 10min, 30min), 30min auto power off (default) |
| Battery Life | ≥ 6 hours |
| Charging Time | 4 hours |
| Charging Voltage / Current | 5V/2A |
| Image Storage Location | Micro SD card |
| Power | A single Li-ion 3.7V/5000mAh 26650 battery |
| Display | 2.8" TFT LCD |
| Product Color | Red and Gray |
| Dimension | 236 * 75.5 * 86mm |
| Standard Accessories | Manual, Type-C USB cable, 16GB TF card |
| Standard Carton Gross Weight | 2.2kg |
